  • Mechanical Buzzer HE-1268
Mechanical Buzzer HE-1268

Mechanical Buzzer HE-1268

  • Product description: Mechanical Buzzer HE-1268 - Pin terminal type , 23x 23x 17mm Worked with 220V DC,Output 78dB
  • INQUIRY

Mechanical Buzzer , Electromechanical Buzzer HE-1268

Buzzer Datasheet:
Pin terminal type

23x 23x 17mm  Worked with 220V DC,Output 78dB at 10cm


TYPE

UNIT

HE-1268

Min.Sound Output at20cm

dB

78

Rated Voltage

VDC

220

Operating Voltage

VDC

180～260

Max. Current Consumption

mA

30

Coil Resistance

Ω

4000±10%

Operating Temperature

℃

-25～+75

Storage Temperature

℃

-25～+85

Weight

g

20

Value applying at rated voltage

DIMENSIONS     Unit:mm     Tolerance:±0.5
